Product
EX39HDMI2.0 Repeater, Support 4K@60Hz
FX-EX39
1 Feature
l lBandwidth upto 18Gbps, Resolution upto 4Kx2K@60Hz, YUV 4:4:4
l lTransmit upto 25m under 4Kx2K@60Hz, YUV 4:4:4, 50m under 1080P@60Hz
l l1xHDMI in, 1xHDMI out, 1xDC receptacle
l lConnect the included DC to USB AM cable when the power is insufficient
l lHDCP2.2 Compliant
l lCEC Pass through
l lSupport 3D
l lNo need power supply
l Dimension (L×W×H):52x45x21mm
l Net Weight:128g
2 SPECIFICATIONS
|
Input |
1x HDMI |
|
Output |
1x HDMI |
|
Maximum Range |
4K@60Hz, YUV 4:4:4, 25m (15m to source + 10m to display)
4K@30Hz, 40m (25m to source + 15m to display)
1080P@60Hz, 50m (30m to source + 20m to display)
|
|
Maximum Resolution |
4K@60Hz, 4:4:4 |
|
Data transfer speed rate |
18Gbps(Maximum) |
|
HDMI Compliance |
Up to HDMI2.0 |
|
HDCP Compliance |
Up to HDCP2.2 |
|
Operating Temperature Range |
-5 to +65℃(+23 to +149℉) |
|
Operating Humidity Range |
5 to 90%RH (No Condensation) |
|
Support Video Color Format |
Deep color 36bit |
|
Support Audio Format |
DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD |
|
Power consumption |
1watts(Maximum) |
|
External Power Source (optional) |
5V 150mA on DC receptacle |
|
Dimension (L×W×H) |
52x45x21mm |
|
Net Weight |
128g |
