Product
HDMI2.0 Repeater, Support 4K@60Hz
FX-EX29
1 Feature
l Bandwidth up to 18Gbps, Resolution up to 4Kx2K@60Hz, YUV 4:4:4
l Transmitter up to 25m under 4K@60Hz, 30m under 4K@30Hz
l Support 3D
l CEC Pass through
l HDCP2.2/1.4 Compliant
l Compact size
l Power consumption is less the 1W
l No need power supply
l Dimension (L×W×H):49.2x27x13.2mm
l Net Weight:10g
2 SPECIFICATIONS
|
Operating Temperature Range |
-5 to +65℃(+23 to +149℉) |
|
Operating Humidity Range |
5 to 90%RH (No Condensation) |
|
Input Video Signal |
0.5-1.0 Volts P-P |
|
Input DDC Signal |
5 volts p-p(TTL) |
|
Data transfer speed rate |
18Gbps(Maximum) |
|
Video Format Supported |
DTV/HDTV:
480i/576i/480P/576P/720P/1080i/1080P/
4Kx2K@60Hz/YUV 4:4:4
3D video support |
|
Video Output |
|
|
Support Video Color Format |
xv-YCC/deep color 36bit |
|
Support Audio Format |
DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD |
|
Power consumption |
1watts(Maximum) |
|
Dimension (L×W×H) |
49.2x27x13.2mm |
|
Net Weight |
0.01g |
